Motherboard Gigabyte TRX40 AORUS PRO WIFI Review

The Gigabyte TRX40 AORUS PRO WIFI ATX sTRX4 motherboard supports third-generation AMD Ryzen Threadripper processors. This motherboard is equipped with Quad Channel ECC / Non-ECC Unbuffered DDR4, 8 DIMMM, 12-2 Phases Infineon Digital VRM Solution with 70A Power Stage, Advanced Thermal Design with Fins-Heat Arraysink, LAN Intel 3 Ultra-Fast NVMe PCIe 4.0 x4 M.2 with thermal protections, Intel WiFi 6 802.11ax 2T2R and BT 5, 120dB SNR AMP-UP Audio with audio capacitors alc1220-VB and WIMA, RGB FUSION 2.0 with LED design with multi-zone addresses.

This AMD motherboard supports mesmerizing LEDs and RGB LED strips, 5 smart fans equipped with multiple temperature sensors, hybrid fan heads with FAN STOP, USB 3.2 Gen 2 Type-C front and rear™ head, update Q-Flash Plus bios without installing CPU with memory and graphics card.Gigabyte TRX40 AORUS PRO WIFI ATX sTRX4 MotherboardThis TRX40 AORUS PRO WIFI finds a perfect balance between style and performance by combining the acclaimed Finsink-Array heatsink with the tube to provide lower MOSFET temperatures for fans, overclockers and professional players. A high-end product must be future-proof for the system to keep up with the latest technologies. TRX40 AORUS PRO WIFI provides the entire next-generation network, storage, and WIFI connectivity to keep you up to date.

The position of that long voltage regulator required that the DIMM positioning would invade the space of the pcie slot, so that the top x16 slot aligns with the second slot on the board in the box. Gigabyte still installs two triple slot cards in the first and third slots and configures both cards with sixteen tracks. Since eight of the CPU’s 64 built-in PCIe lanes are dedicated as a chipset connection and eight M.2 units, which leaves sixteen tracks split between the second and bottom slots in eight slot lanes.Gigabyte TRX40 AORUS PRO WIFI ATX sTRX4 Motherboard

Because the second and bottom slots are wired like x8, a passive M.2 x16 PCIe adapter, like the one included on the ASRock tab, does not support all four M.2 slots. Gigabyte has an active tab that could change drives from two x4 to four x2, but it is not included in the box with this tab.Photo:GIGABYTE

To unlock the full potential of the third-generation Amd Ryzen Threadripper CPU, the motherboard requires the best CPU power design with the best quality components and the design capability of GIGABYTE R&D, TRX40 AORUS PRO WIFI is a real beast motherboard between them. This motherboard comes with full PCIe 4.0 Design, which includes PCIe 4.0 Ready PCB, PCIe 4.0 Slots, PCIe 4.0 M.2 connectors and offers highly optimized performance and flexibility required for advanced users and fans of extreme games. This moptherboard also features RGB FUSION 2.0 and offers users the ability to control onboard, external light strips and/or AORUS devices with RGB LED/RGB Addressables to make their PC more unique and stylish. This exclusive Gigabyte TRX40 AORUS PRO comes with a 3-year warranty.Gigabyte TRX40 AORUS PRO WIFI ATX sTRX4 Motherboard

  • Supports 3rd Gen AMD Ryzen™ Threadripper™ Processors
  • Quad Channel ECC/ Non-ECC Unbuffered DDR4, 8 DIMMs
  • 12+2 Phases Infineon Digital VRM Solution with 70A Power Stage
  • Advanced Thermal Design with Fins-Array Heatsink
  • Intel® GbE LAN with cFosSpeed Internet Accelerator
  • 3 Ultra-Fast NVMe PCIe 4.0 x4 M.2 with Thermal Guards
  • Onboard Intel® WiFi 6 802.11ax 2T2R & BT 5
  • 120dB SNR AMP-UP Audio with ALC1220-VB and WIMA Audio Capacitors
  • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Support Addressable LED & RGB LED Strips
  • Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
  • Front & Rear USB 3.2 Gen 2 Type-C™ Header
  • Q-Flash Plus Update BIOS Without Installing CPU, Memory and Graphics Card
  • TRX40 AORUS Motherboard Price: about 430,00€
Basic Information
Supported CPU AMD Socket sTRX4: Support 3rd Generation AMD Ryzen Threadripper processors
Chipset AMD TRX40
BIOS 2 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
Support for DualBIOS™
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Form Factor ATX Form Factor; 30.5cm x 24.4cm
Audio Realtek ALC4050H codec+ ALC1220-VB codec
Support for DTS: X Ultra
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
Expansion Slots
PCI 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
1 x PCI Express x1 slot
(All of the PCI Express slots conform to PCI Express 4.0 standard.)
M.2 Socket 3 x M.2 Socket 3 connectors
Memory
Type Dual Channel DDR4 Memory Technology
Slots 8 x DDR4 DIMM sockets
Supported Memory – Support for DDR4 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
– Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
– Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
– Support for Extreme Memory Profile (XMP) memory modules
Maximum Mamory up to 256 GB
Graphics
Graphics Multi-Graphics Technology
Support for AMD Quad-GPU CrossFire and 3-Way/2-Way AMD CrossFire technologies
Support for NVIDIA Quad-GPU SLI and3-Way/2-Way NVIDIA SLI technologies
Connector & Ports
USB (s) CPU:
3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support
Chipset:
2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
1 x USB Type-C™ port with USB 3.2 Gen 2/Gen 1 support, available through the internal USB header
4 x USB 3.2 Gen 1 ports available through the internal USB headers
Chipset + 2 USB 2.0 Hubs:
8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
LAN Port (s) Intel GbE LAN chip (10/100/1000 Mbit)
Supported Storage CPU:
1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M)
1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2Q)
Chipset:
1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2P)
8 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, and RAID 10
Audio 1 x front panel audio header
Realtek ALC4050H codec+ ALC1220-VB codec
Support for DTS:X Ultra
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
Internal I/O Ports iTE I/O Controller Chip
Warranty Information
Manufacturing Warranty 3 years warranty
