Type | Single-lens reflex digital camera |
|---|
Lens mount | Nikon F mount (with AF coupling and AF contacts) |
|---|
Effective angle of view | Nikon FX format |
|---|
Image sensor | FX, CMOS, 35.9 mm x 23.9 mm |
|---|
Total pixels | 25.28 million |
|---|
Dust-reduction system | Image sensor cleaning, Image Dust Off reference data (Capture NX-D software required) |
|---|
Effective pixels | 24.5 million |
|---|
Image size (pixels) | FX (36×24) image area: (L)6048, x4024 (24.3million), (M)4528, x3016 (13.7million), (S)3024, x2016 (6.1million). DX (24×16) image area: (L)3936, x2624 (10.3million), (M)2944, x1968 (5.8million), (S)1968, x1312 (2.6million). 1:1 (24×24) image area: (L)4016, x4016 (16.1million), (M)3008, x3008 (9.0million), (S)2000, x2000 (4.0million). 16:9 (36×20) image area: (L)6048, x3400 (20.6million), (M)4528, x2544 (11.5million), (S)3024, x1696 (5.1million). Photographs taken while filming movies at a frame size of 3840 x 2160: 3840 x 2160 Photographs taken while filming movies at other frame sizes: 1920 x 1080 |
|---|
Storage file formats | NEF (RAW): 12 or 14 bit (lossless compressed or compressed), JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8), or basic (approx. 1:16) compression; size-priority and optimal-quality compression available, NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats |
|---|
Picture Control System | Auto, Standard, Neutral, Vivid, Monochrome, Portrait, Landscape, Flat, Creative Picture Controls (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon); selected Picture Control can be modified; storage for custom Picture Controls |
|---|
Storage media | SD, SDHC (UHS-II compliant), SDXC (UHS-II compliant) |
|---|
Dual card slot | 2 Secure Digital (SD) cards; the card in Slot 2 can be used for overflow or backup storage or for separate storage of NEF (RAW) and JPEG images; pictures can be copied between cards. |
|---|
File system | DCF 2.0, Exif 2.31 |
|---|
Viewfinder | Eye-level pentaprism single-lens reflex viewfinder |
|---|
Frame coverage | FX: Approx. 100% horizontal and 100% vertical, DX: Approx. 97% horizontal and 97% vertical, 1:1: Approx. 97% horizontal and 100% vertical, 16:9: Approx. 100% horizontal and 97% vertical |
|---|
Magnification | Approx. 0.7x (50 mm f/1.4 lens at infinity, -1.0 m-¹) |
|---|
Eyepoint | 21 mm (-1.0 m-¹; from center surface of viewfinder eyepiece lens) |
|---|
Diopter adjustment | -3 to +1 m-¹ |
|---|
Focusing screen | Type B BriteView Clear Matte Mark VIII screen (with AF-area brackets; framing grid can be displayed) |
|---|
Reflex mirror | Quick return |
|---|
Depth-of-field preview | Yes, pressing Pv button stops lens aperture down to value selected by user (A and M modes) or by camera (P and S modes) |
|---|
Lens aperture | Instant return, electronically controlled |
|---|
Compatible lenses | Types G, E, and D (some restrictions apply to PC lenses), other AF NIKKOR lenses (excluding IX NIKKOR lenses and lenses for the F3AF), AI-P NIKKOR lenses DX lenses (using [DX (24 × 16)] image area), non-CPU AI lenses (modes A and M only), during viewfinder photography, the electronic rangefinder can be used with lenses that have a maximum aperture of f/5.6 or faster. With lenses that have a maximum aperture of f/8 or faster, the electronic rangefinder supports 11 focus points. |
|---|
Shutter type | Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic front-curtain shutter; electronic shutter |
|---|
Shutter speed | 1/8000 to 30 s (choose from step sizes of 1/3 and 1/2 EV, extendable to 900 s in mode M); Bulb; Time; X200 |
|---|
Flash sync speed | X=1/200 s; synchronizes with shutter at 1/200 s or slower Auto FP high-speed sync supported |
|---|
Release mode | S (single frame), CL (continuous low speed), CH (continuous high speed), Q (quiet shutter-release), QC (quiet continuous shutter-release), Self-timer, MUP (mirror up) |
|---|
Frame advance rate | Up to 7 fps. CL: 1 to 6 fps (viewfinder photography); 1 to 3 fps (live view photography). CH: 7 fps; when shooting NEF/RAW pictures during silent photography, either 8 fps (bit depth 14 bits) or 12 fps (bit depth 12 bits) QC: 3 fps |
|---|
Self-timer | 2 s, 5 s, 10 s, 20 s; 1 to 9 exposures at intervals of 0.5, 1, 2, or 3 s |
|---|
Exposure metering | Viewfinder photography: TTL exposure metering using RGB sensor with approximately 180K (180,000) pixels; Live view: TTL exposure metering performed by image sensor |
|---|
Metering method | Matrix: 3D color matrix metering III (type G, E, and D lenses); color matrix metering III (other CPU lenses); color matrix metering available with non-CPU lenses if user provides lens data Center-weighted: Weight of 75% given to 12 mm circle in center of frame; diameter of circle can be changed to 8, 15, or 20 mm, or weighting can be based on average of entire frame (non-CPU and AF-S Fisheye NIKKOR 8-15mm f/3.5-4.5E ED lenses use 12-mm circle); Spot: Meters circle approximately 4 mm in diameter (about 1.5% of frame) centered on selected focus point (on center focus point when non-CPU or AF-S Fisheye NIKKOR 8-15mm f/3.5-4.5E ED lens is used); Highlight-weighted: Available with type G, E, and D lenses |
|---|
Metering range (ISO 100, f/1.4 lens, 20 °C/68 °F) | Matrix and center-weighted metering: -3 to +20 EV; Spot metering: 2 to 20 EV; Highlight-weighted metering: 0 to 20 EV |
|---|
Exposure meter coupling | CPU, AI |
|---|
Mode | Auto, P: programmed auto with flexible program, S: shutter-priority auto, A: aperture-priority auto, M: manual EFCT, Special effects modes: night vision; super vivid; pop; photo illustration; toy camera effect; miniature effect; selective color; silhouette; high key; low key U1 and U2: user settings |
|---|
Exposure compensation | –5 to +5EV; -3 to +3 EV when filming movies (choose from step sizes of 1/3 and 1/2 EV) available in P, S, A, M, and EFCT modes |
|---|
Exposure lock | Luminosity locked at detected value |
|---|
ISO sensitivity | ISO 100 to 51200 (choose from step sizes of 1/3 and 1/2 EV); can also be set to approx. 0.3, 0.5, 0.7, or 1 EV (ISO 50 equivalent) below ISO 100, or to approx. 0.3, 0.5, 0.7, 1, or 2 EV (ISO 204800 equivalent) above ISO 51200; auto ISO sensitivity control available (Recommended Exposure Index) |
|---|
Active D-Lighting | Can be selected from Auto, Extra high, High, Normal, Low, or Off |
|---|
Autofocus | Viewfinder photography: TTL phase detection performed using Advanced Multi-CAM 3500 II autofocus sensor module with support for 51 focus points (including 15 cross-type sensors; f/8 supported by 11 sensors); autofocus fine-tuning supported Live view: Hybrid phase-detection/contrast-detect AF performed by image sensor; autofocus fine-tuning supported |
|---|
Detection range | Viewfinder photography¹: -3 to +19 EV; Live view²: -5 to +19 EV; -7 to +19 EV with low-light AF |
|---|
Lens servo | Single-servo AF (AF-S), Continuous-servo AF (AF-C), AF mode auto-switch (AF-A, still photography only), full-time AF (AF-F, movie recording only); predictive focus tracking activated automatically according to subject status, Manual focus (M): Electronic rangefinder can be used |
|---|
Focus points | Viewfinder photography: 51 points with [All points] selected for Custom Setting a6 [Focus points used], 11 points with [Every other point] selected, Live view³: 273 points with [All points] selected for Custom Setting a6 [Focus points used], 77 points with [Every other point] selected |
|---|
AF-area mode | Viewfinder photography: Single-point AF, 9-, 21-, or 51- point dynamic-area AF, 3D-tracking, group-area AF, auto-area AF Live view: Pinpoint AF (still photography only, single-servo AF/AF-S), single-point AF, dynamic-area AF (still photography only, continuous-servo AF/AF-C), wide-area AF (S), wide-area AF (L), auto-area AF |
|---|
Focus lock | Focus can be locked by pressing shutter-release button halfway (single-servo AF/AF-S) or by pressing AE-L/AF-L button |
|---|
Flash control | Viewfinder photography: TTL flash control performed by RGB sensor with approximately 180K (180,000) pixels; Live view photography: TTL flash control performed by image sensor i-TTL balanced fill flash for digital SLR available with matrix, center-weighted, and highlight-weighted metering; standard i-TTL fill-flash for digital SLR available with spot metering |
|---|
Flash modes | Front-curtain sync, red-eye reduction, slow sync, red-eye reduction with slow sync, rear-curtain sync, off |
|---|
Flash compensation | –3 to +1 EV (choose from step sizes of 1/3 and 1/2 EV) available in P, S, A, and M modes |
|---|
Flash-ready indicator | Lights when optional flash unit is fully charged; flashes after flash is fired at full output |
|---|
Accessory shoe | ISO 518 hot-shoe with sync and data contacts and safety lock |
|---|
Nikon Creative Lighting System | i-TTL flash control, radio-controlled Advanced Wireless Lighting, optical Advanced Wireless Lighting, modeling illumination, FV lock, Color Information Communication, auto FP high-speed sync, AF-assist for multi-area AF (viewfinder photography), unified flash control |
|---|
Sync terminal | AS-15 sync terminal adapter (available separately) |
|---|
White balance | Auto (3 types), natural light auto, direct sunlight, cloudy, shade, incandescent, fluorescent (7 types), flash, choose color temperature (2500 K to 10,000 K), preset manual (up to 6 values can be stored, spot white balance measurement available during live view photography), all except choose color temperature with fine-tuning |
|---|
White balance bracketing | Exposure and/or flash, white balance, and ADL |
|---|
Live View – Modes | Photo live view, Movie live view |
|---|
Movie – metering | TTL metering using camera image sensor |
|---|
Movie – metering method | Matrix, center-weighted, or highlight-weighted |
|---|
Movie – frame size (pixels) and frame rate | 3840 x 2160 (4K UHD); 30p (progressive), 25p, 24p 1920 x 1080; 120p, 100p, 60p, 50p, 30p, 25p, 24p 1920 x 1080 (slow-motion); 30p x4, 25p x4, 24p x5⁴. Actual frame rates for 120p, 100p, 60p, 50p, 30p, 25p, and 24p are 119.88, 100, 59.94, 50, 29.97, 25, and 23.976 fps respectively |
|---|
Movie – file format | MOV, MP4 |
|---|
Movie – video compression | H.264/MPEG-4 Advanced Video Coding |
|---|
Movie – audio recording format | Linear PCM, AAC |
|---|
Movie – audio recording device | Built-in stereo or external microphone with attenuator option; sensitivity adjustable |
|---|
Movie – ISO sensitivity | Manual selection (ISO 100 to 51200); choose from step sizes of 1/3 and 1/2 EV) with additional options available equivalent to approximately 0.3, 0.5, 0.7, 1, or 2 EV (ISO 204800 equivalent) above ISO 51200; auto ISO sensitivity control (ISO 100 to Hi 2) available with selectable upper limit |
|---|
Movie – Other options | Time-lapse movie recording, electronic vibration reduction, time codes, logarithmic (N-Log) and HDR (HLG) movie output |
|---|
Monitor | 8-cm (3.2–in.), approx. 2359k-dot (XGA) tilting TFT touch-sensitive LCD with 170° viewing angle, approximately 100% frame coverage, 11-level manual brightness adjustment, and color balance control |
|---|
Playback | Full-frame and thumbnail (4, 9, or 72 images or calendar) playback with playback zoom, playback zoom cropping, movie playback, photo and/or movie slide shows, histogram display, highlights, photo information, location data display, picture rating, auto image rotation, and index marking |
|---|
USB | Type C connector (SuperSpeed USB); connection to built-in USB port is recommended |
|---|
HDMI output | Type C HDMI connector |
|---|
Audio input | Stereo mini-pin jack (3.5 mm diameter; plug-in power supported) |
|---|
Audio output | Stereo mini-pin jack (3.5 mm diameter) |
|---|
Accessory terminal(s) | Built-in (can be used with accessories such as the MC-DC2 remote cord) |
|---|
Wi-Fi (Wireless LAN) standards | IEEE 802.11b/g/n/a/ac, 2412 to 2462 MHz (channel 11) and 5180 to 5320 MHz, 2.4 GHz band: 2.9 dBm, 5 GHz band: 8.7 dBm, Open system, WPA2-PSK |
|---|
Bluetooth standards | Bluetooth Specification Version 4.2, Bluetooth: 2402 to 2480 MHz, Bluetooth Low Energy: 2402 to 2480 MHz, Bluetooth: –2.6 dBm, Bluetooth Low Energy: –4.1 dBm; Range: approximately 10 m (32 ft)⁵ |
|---|
Battery | One EN-EL15b rechargeable Li-ion battery⁶ |
|---|
AC adapter | EH-5d/EH-5c/EH-5b AC adapter; requires EP-5B power connector (available separately) |
|---|
Tripod socket | 1/4–in. (ISO 1222) |
|---|
Dimensions (W x H x D) | Approx. 143.5 x 115.5 x 76 mm (5.7 x 4.6 x 3 in.) |
|---|
Weight | Approx. 840 g (1 lb. 13.7 oz.), with battery and SD memory card but without body cap; approx. 755 g/1 lb. 10.7 oz. (camera body only) |
|---|
Operating environment – temperature | 0 °C to 40 °C (+32 °F to 104 °F) |
|---|
Operating environment – humidity | 85% or less (no condensation) |
|---|
Supplied accessories | BF-1B Body Cap, DK-31 Rubber Eyecup (comes attached to camera), EN-EL15b Rechargeable Li-ion Battery with Terminal Cover, MH-25a Battery Charger (comes with either an AC wall adapter or power cable of a type and shape that varies with the country or region of sale), DK-5 Eyepiece Cap, UC-E24 USB Cable, AN-DC21 Strap |
|---|
