75″ 4K Ultra HD Premium Hisense 75U9GQTUK

Admin
-
0
75″ 4K Ultra HD Premium Hisense 75U9GQTUK

ULED created possibly even better by Mini LED
Hisense’s flagship ULED TV is made even better by Mini LED. Mini LED works by using hundreds of little LED backlights to significantly enhance contrast, black levels and fine detail. With 1280 individual dimming zones, the Hisense 75U9GQTUK has more than 10x the number of zones in comparison to their regular ULED TVs. Quantum Dot Colour becomes closer to the original than ever before, with over a billion true-to-life colours. 100Hz panel refresh makes for the smoothest motion – while always keeping the detail crisp and clear.

Hisense 75U9GQTUK

Ultra HD Premium – for supreme picture quality
The top rated special panel used in the Hisense 75U9GQTUK meets the maximum requirements for picture quality – Ultra HD Premium. Full Array Local Dimming Pro features 1280, separately controlled dimming zones for amazing contrast levels and exceptional picture realism. With a optimum brightness of 2000 nits, the Hisense 75U9GQTUK provides out the picture’s real colour.

Discover the picture just exactly as originally intended, through Filmmaker Mode
Filmmaker Mode helps make the best of any kind of movie. Made in collaboration with filmmakers and studios, Filmmaker Mode lets you experience the cinematic vision, exactly as the movie director planned. Over-riding the TV’s own motion and picture processing, Filmmaker Mode presents the appropriate aspect ratio, colour and frame rate – just as the filmmakers intended.

IMAX Enhanced
Absolutely nothing beats the big screen excite of IMAX and now, many thanks to IMAX enhanced, you can enjoy the strength of IMAX on your TV, as well. Applied with IMAX certified 4K HDR content, IMAX Enhanced uses their exclusive digital remastering technology (DMR) to give you ultra-vivid images.

What is IMAX Enhanced?

IMAX Enhanced is a certification program developed by IMAX, a company that specializes in creating high-quality cinematic experiences, in partnership with DTS, a technology company that specializes in audio solutions. The program is designed to provide consumers with a high-quality home entertainment experience that is faithful to the original IMAX theatrical experience.

To be certified as IMAX Enhanced, a product must meet certain performance standards and be able to support certain technologies. For example, IMAX Enhanced TVs must have a high level of picture quality and support high dynamic range (HDR) content, as well as be able to decode and play back IMAX Enhanced audio tracks. IMAX Enhanced content is created using special post-production techniques that are designed to optimize the content for home viewing, including remastering the picture and sound to take advantage of the capabilities of IMAX Enhanced TVs and other devices.

IMAX Enhanced content is available on a range of platforms, including streaming services, Blu-ray discs, and Ultra HD Blu-ray discs. It can be watched on IMAX Enhanced TVs and other devices that are certified to support the program, such as home theater systems and soundbars.

Dolby Vision IQ – the ultimate detail
Dolby Vision IQ takes Dolby Vision to the next stage, making it the ultimate HDR-type picture processor chip. Dolby Vision IQ version uses data within the signal and light sensors inside of the TV to modify the picture quality for the very best contrast. This increases the picture’s brightness, with no ‘washing out’ the depth. You get a constant picture quality, however light or dark your room is. Whether you’re watching a really brightly lit sports event or perhaps moody movie, Dolby Vision IQ adjusts to fit.

Multi-format HDR assistance for a gorgeous picture from all sources
As well as Dolby Vision and Vision IQ, this Hisense 75” TV also provides multi-format HDR – including HDR10+. HDR10+ offers scene-by-scene HDR mastering for the truest, most precise HDR picture technology. Every scene is optimised, which means the optimum amount of detail is displayed – even in the brightest or darkest moments.

Sound boost
Providing a 3.1.2 speaker system, Dolby Atmos DTS Virtual:X and front-firing speakers, the Hisense 75U9GQTUK sounds way significantly better than most TVs. The speaker system delivers full, room-filling sound. Use Dolby Atmos encoded material and the sound gets even much better, with ‘wrap around’ Dolby sound for cinematic environment. Photo: Hisense

Game on
Featuring a specific Game Mode, the 75U9GQTUK makes the ideal gaming monitor/TV combination. With 4K 60Hz VRR (Variable Refresh Rate) and ALLM (Auto Low Latency Mode), gaming is optimised for a quicker, more responsive feel.

Hisense design and style
Providing Hisense’s Narrow Frame, super-slim bezel, the Hisense 75U9GQTUK performs as remarkably in the style stakes as it does sound and picture. A elegant, pure metal main stand design includes integral cable management for a nice looking finish.

VIDAA U5 for Smart TV
With Hisense’s Smart OS known as VIDAA U5, this Hisense 75” TV makes Smart TV very simple. Bringing together a huge range of applications and devices, VIDAA U5 lets you switch between them all in 3 steps or less – no more complicated sub-menus. You’ll get simple access to all your favourite TV services, including Netflix, Prime Video, YouTube and Freeview Play. VIDAA U5 is a Smart TV platform developed by Hisense electronics company. It is designed to provide users with a seamless and intuitive interface for accessing and navigating content on their Hisense TV. The platform offers a range of features, including access to streaming services such as Netflix, Amazon Prime, and Hulu, as well as the ability to browse the internet and access a variety of apps. It also includes features like voice control and personalized recommendations to help users find and watch the content they want. VIDAA U5 is available on a range of Hisense TVs and is designed to be easy to use and navigate, with a simple and clean interface.

Voice control your TV
Supplied with voice control, the 75U9GQTUK can make navigating via control features a breeze. Alexa is built/in, with the Google Assistant also accessible. For easy, simple control, only ask.

Freeview Play for catch-up TV
Freeview Play makes catch-up TV very easy. Find programs from BBC iPlayer, the ITV Hub, All4 and Demand 5 sitting alongside 70 TV Channels and up to 15 HD channels. Simply scroll back in your TV guide to watch shows you skipped from the last 7 days. Only make sure your TV is connected to the internet and you’re good to go.

Hisense 75U9GQTUK

Connection upgrade
Fitted with 4 HDMI sockets, the Hisense 75U9GQTUK is ideal for connecting to your TV set-top box, UHD Blu-ray player, video games console and some other device. Other connections include double USB sockets – excellent for connecting media devices and playing back music, images and video. Throw in an optical connection for a soundbar/base and you have every little thing you need from a high end TV. Hisense 75U9GQTUK price: £2,599.00

Get a cinematic picture, in your house, with the Hisense 75U9GQTUK TV.

Hisense 75U9GQTUK specs:

  • Model Number 75U9GQTUK
  • Series U9G
  • Model Year 2021
  • Front Colour Black

Display

  • Screen Size 75″
  • Resolution Ultra HD 3840×2160
  • Backlight Type DLED Local Dimming Zone Pro
  • Curvature Rate 0
  • Quantum Dot Technology Yes
  • Panel Bit Depth 8bit + FRC
  • Peak Brightness (nits) 3000
  • Viewing Angle (H/V) 178°
  • Refresh Rate 120Hz
  • HDR (High Dynamic Range) HDR10, HLG
  • HDR Classification HDR10+
  • Local Dimming Yes
  • Wide Colour Gamut Yes
  • 3D No

Processor Features

  • Processor Quad Core/NT72671D
  • 4K Upscaling Yes
  • Decoder HEVC (H.265),VP9,H.264,MPEG4, MPEG2,AV1
  • Input Lag <20ms (Game Mode)
  • 3D Digital Comb Filter Yes

Audio

  • Sound Output 90W: 2*15W+2*10W+20W+2*10W
  • NICAM Stereo Yes
  • Audio Enhancement Dolby MS12,Dolby Atmos
  • User Equaliser Yes

Smart Service

  • User Interface VIDAA U5.0
  • Web Browser Yes (VEWD)
  • Freeview Play Yes
  • Netflix Yes
  • Amazon Yes
  • YouTube Yes
  • Remote One Touch Access No
  • Application Store Yes

Connectivity

  • HDMI Input HDMI2.0 (ALLM, VRR)
  • HDMI Input HDMI2.0 (eARC, ALLM, VRR)
  • HDMI Input HDMI2.0 (ALLM, VRR)
  • HDMI Input HDMI2.0 (ALLM, VRR)
  • USB USB (3.0) 1
  • USB USB (2.0) 1
  • Digital Audio Output (Optical) Yes
  • Ethernet (LAN) Yes
  • Wi-Fi IEEE 802.11 a/b/g/n/ac (2.4G and 5G)
  • Headphone Out Yes
  • Component In (Y/Pb/Pr) No
  • Composite In (AV) 1
  • CI Slot Yes (CI + ECP)
  • RF In (Terrestrial / Cable / Satellite Input) 2
  • SCART No
  • VGA Input No

TV Tuner / Broadcasting

  • Digital & Analog Tuner DVB-T2/T/C/S2/S
  • Freeview HD Yes
  • Freesat HD No
  • EPG Yes
  • Extended PVR No
  • Time Shift Yes
  • Parental Control Yes

Convenience

  • Media Player Yes (Video, Audio, Picture)
  • Multi-Language OSD English, French, Spanish

Eco & Power Supply

  • Power Supply 100V-240V 50/60Hz
  • Energy Efficiency Class G
  • Power Consumption (In Standby) ≤0.5 W
  • Mercury Content Yes – this television contains lead only in certain parts or components，in accordance with existing exemption clauses under the RoHS Directive.
  • Lead Content Yes – this television contains lead only in certain parts or components，in accordance with existing exemption clauses under the RoHS Directive.

Weight & Dimensions

  • Product Weight (Packaged) 73.7kg
  • Product Weight (With Stand) 53.7kg
  • Product Weight (Without Stand) 44.7kg
  • Dimensions (Packaged) (W X H X D) 1847×397×1175mm
  • Dimensions (With Stand) (W X H X D) 1679×321×1024mm
  • Dimensions (Without Stand) (W X H X D) 1679×70×1007mm
  • VESA Wall Mount Compatible 600×400 mm

Accessories

  • Remote Control Yes
  • Batteries (Remote Control) AAAx2
  • Quick Set Up Guide Yes
  • User Manual Yes

DMP Format

  • Picture .jpeg,.bmp,.PNG,.GIF,.mpo
  • Video .AVI, .WMV, .MP4, .MOV, .3GP, .MKV, .MPG, .MPEG, .VOB, .FLV, .WebM, .OGM,
  • Container Formats AVI,MP4,MKV,TS,FLV OGG
  • Audio .wma,.wmv,.mp4,.FLAC,.MP2,.MP3 music (mp3 aac wma wav)

8K Sony BRAVIA MASTER Series XR-85Z9J

Admin
-
0
8K Sony BRAVIA MASTER Series XR-85Z9J

Sony’s best 85″ LED TV for 2021

Sony is well versed in the process of film production, including filming and editing. This experience is reflected in his much-loved television line. The Z9J series is Sony’s flagship, the best of the best, bringing together all its best updates for 2021. The image of this 8K TV really stands out, offering a rich and realistic level of detail that puts it above even the best 4K models.

Powerful “cognitive” treatment
Sony is famous for its powerful processing, and they just raised the bar. The XR™ cognitive processor harnesses the power of machine learning and combines it with a human perspective to create a truly immersive experience. Sounds like the beginning of a sci-fi novel, I know, but listen to me.

BRAVIA XR Z9J 8K

A wide range of elements (contrast, color, texture, etc.) are analyzed in each image to detect and enhance key focal points. The number of specific details adjusted can reach hundreds of thousands. Because these focal points are based on how we actually see the world, the picture seems deeper and more realistic.

In short, Sony’s new cognitive processing technology produces a sharp, hyper-detailed image that is almost as real as a TV.

Realistic and vibrant color
The TV’s TRILUMINOS PRO™ XR display technology further enriches your experience by offering a wider range of vibrant colors. Additional subtlety in the variation of colors gives the image an authentic and natural look.

Enhanced by HDR
The Sony XR-85z9j also supports Dolby Vision® HDR (High Dynamic Range). This system adjusts brightness and color levels scene by scene to improve contrast and detail with Dolby Vision encoded programs, many of which are available through popular streaming services.

BRAVIA XR Z9J 8K

Stunning 3D TV sound
Sony’s cognitive processing is not only for the image, but is also used to enhance sound, always ensuring 3D sound, regardless of its source. The processing is combined with Sony’s innovative frame tweeter design, which allows the TV frame to produce sound. Sound effects can be projected vertically or laterally and positioned where the source of a sound appears on the screen. This allows the XR-85z9j to produce immersive 3D sound without the need for additional equipment.

Streaming with Google TV
The integrated Google TV smart app platform puts a wide range of streaming services, from Netflix® to Disney+, at your fingertips and consolidates search results into a single user interface. This saves you a lot of time, allowing you to search for content on several services at once. Google TV will quickly point you in the right direction. No need to search individually in each service you have signed up for.

BRAVIA XR Z9J 8K

Convenient voice control
You can browse the basic features of your TV and also search Google TV with your only voice. The included remote control has a built-in microphone that can capture commands and communicate them to the TV. The TV also supports Google Assistant and Alexa, allowing you to integrate your TV into your existing smart home system. Photo: Sony

Accessibility

Accessibility Shortcut

Yes

Audio Description (Audio key)

Yes

Closed Caption

Closed Caption

Screen Reader

Yes

Text Magnification

Yes

Voice Search

Yes

Built-in Tuner

CI+

–

Number of Tuners (Sat)

–

Number of Tuners (Terrestrial/Cable)

1(Digital/Analog)

TV System (Analog)

M

TV System (Digital Cable)

Clear QAM

TV System (Digital Sat)

–

TV System (Digital Terrestrial)

ATSC/ATSC 3.0(NEXTGEN TV)

Tuner Channel Coverage (Analog)

VHF: 2-13/UHF: 14-69/CATV: 1-135

Tuner Channel Coverage (Digital Cable)

CATV: 1-135

Tuner Channel Coverage (Digital Terrestrial)

VHF: 2–13/UHF: 14–69 (14–36 for ATSC 3.0)

Connectivity

APPLE AIRPLAY

Yes

Review: Sony HT-A7000 premium soundbar

Admin
-
0
Review: Sony HT-A7000 premium soundbar

The Sony HT-A7000 is a soundbar that was released in 2021. It is designed to enhance the audio quality of your TV and home theater system. Some key features of the HT-A7000 include support for high-resolution audio formats, wireless connectivity, and a built-in subwoofer for deep bass. It has a sleek, modern design and is compatible with a variety of TVs and devices. The HT-A7000 received positive reviews for its excellent sound quality and easy setup.

The Sony HT-A7000 is the manufacturer’s flagship 7.1.2 configuration released in 2021. It has been announced that it supports Sony’s virtual surround engine and S-Force PRO front surround technologies, which help create a more immersive listening experience. You can also upgrade this configuration with a subwoofer and satellites, which are sold separately. Its main competitors are Sonos Arc, Sony HT-A9 and Samsung HW-Q950A.
The Sony HT-A7000 has two subwoofers built into the bar. They are located to the left and right of the central enclosure. You can also purchase a dedicated subwoofer, which is sold separately.

Sony HT-A7000 soundbar

The Sony HT-A7000 is a stylish soundbar with a high-end design. It is mainly made of high-quality plastic with a metal grille on the front. However, unlike the Sony HT-ST5000, the grille cannot be removed to expose the speakers. That said, the grille is transparent enough that you can see the speakers behind it. There is also a glass and fabric cap covering the ignition conductors on top.

The Sony HT-A7000 has an impressive build quality. It is mainly made of plastic, which feels strong and durable, and the metal grille on the front helps protect the drivers inside. On the top there is a glass plate which gives you a more premium feel. The fabric covering the runners getting up is a bit loose, but seems to be of good quality overall. It’s big and heavy, but it’s premium.

The Sony HT-A7000 soundbar offers good stereo audio performance. Its stage is perceived as wide enough thanks to its s-Front PRO Front Surround technology, which uses front speakers to reproduce the sound field. However, their attention is only average, and the sound objects seem to come from a more general area than from a specific, precise location. For a setup with a better audio scenario, check out the Sony HT-A9.

Sony HT-A7000 soundbar

The Sony HT-A7000 is decent for music. It has a room correction function called Sound Field Optimization that automatically optimizes audio playback based on the acoustic characteristics of the room. Its frequency response is neutral, with an extra boom on the bass, making it suitable for most musical genres. However, he strives to sound low-low, so that he does not hear the deep roar in genres like EDM and hip hop. There are not many customization options.

The Sony HT-A7000 soundbar is suitable for dialogue-oriented content such as TV shows. Its discrete center channel allows voices to be more accurately located in a precise position in the sound image, and its balanced frequency response reproduces the dialogue clearly and accurately. There is also a dialogue enhancement feature to make the voices clearer and sharper. However, it does not become very strong, which can be disappointing.

Sony HT-A7000 soundbar

The Sony HT-A7000 soundbar is a solid for movies. Its neutral sound profile makes it possible to reproduce the dialogue clearly and accurately, but it lacks low bass, so you don’t hear the deep rumble in the action-packed scenes. It supports immersive content and atmosphere, although overall its performance is disappointing. Besides, it doesn’t get too loud.

It can be fought that a soundbar will never quite match up to a correct surround sound system, but a really good soundbar still has plenty of potential to make the difference somewhat unimportant. The Sony HT-A7000 is very exceptional, improving the sound experience through genres and content, and adding helpful post-processing and particular tuning where required. Mixed with the Sony SA-SW3 subwoofer, this is a powerful home theatre system but is still simple to set up and operate.
The Sony HT-A7000 bar speaker is pretty big and heavy at 8.7kg. It’s just about the same size as a typical 55 inch tv, and also wide enough that it needs to be set on a large table or home entertainment unit. The dimension (and price) of the HT-A7000 implies that it is ideal paired with a high quality television, and its built-in connection and amplification mean that you don’t need an AV receiver or home theatre amp.
The bar speaker itself looks premium and really beautiful, with a metal grille, shiny surface at the top, and fabric covering the two top-firing overhead channels. The touch controls for power, Bluetooth connectivity, signal source, and volume level are on the top of the soundbar. The front of the HT-A7000 has a small monochrome display that indicates its power status, the source that’s in use, and volume levels. The display was a little bit difficult to read from a distance, but it’s more than enough for the function it serves.

The Sony HT-A7000 soundbar is a premium 7.1.2 configuration released in 2021. It has been announced that it supports S-Force PRO front surround and vertical Surround engine technologies for a more immersive listening experience. Its default audio profile is fairly neutral with an extra punch on the bass, making it suitable for listening to most types of audio content. However, it does not become very strong. In addition, in our subjective listening tests, we found that it is best to adjust the EQ preset based on the content you are listening to, which can be inconvenient for some users. Video: YouTube/Sony Photo: Sony

Sony HT-A7000 soundbar specs:

Main Unit Size – Body Only (W x H x D)

1300x80x142mm

Main Unit Size – Body Only (W x H x D) (INCH)

51 1/4×3 1/4×5 5/8 in

Main Unit Weight – Body Only

8.7 kg

MAIN UNIT WEIGHT – BODY ONLY (OZ)

19lb 2oz

Amplifier

Amplifier Type

Digital Amplifier, S-Master HX

Amplifier Channels

11ch

Power Output (Total)

500W

Subwoofer

Subwoofer Type

Built-in

Interface

Input and Output Terminals

Optical-audio input, Analogue audio input(stereo mini), USB typeA, File System:exFAT/FAT12/16/32,vFAT

IEEE802.11 version

a/b/g/n/ac

Bluetooth

Yes

Bluetooth version

Ver5.0

HDCP2.2

Yes

Audio Formats

HDMI INPUT
Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, Dolby Dual mono, DTS, DTS HD High Resolution Audio, DTS HD Master Audio, DTS ES, DTS 96/24, DTS:X, LPCM
HDMI EARC
Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, Dolby Dual mono, DTS, DTS HD High Resolution Audio, DTS HD Master Audio, DTS ES, DTS 96/24, DTS:X, LPCM
OPTICAL INPUT
Dolby Digital, Dolby Dual mono, DTS, LPCM 2ch
USB
DSD(.dsf / .dff ), Wav, Flac, ALAC(.m4a, .mov), AIFF(.aiff, .aif), HE AAC, AAC, mp3, Monkey Audio, WMA, Ogg Vorbis
BLUETOOTH(RECEIVER)
AAC, SBC, LDAC
BLUETOOTH(TRANSMITTER)
SBC, LDAC

Specs-80 PLUS Gold 500W SilverStone FX500

Admin
-
0
Specs-80 PLUS Gold 500W SilverStone FX500

The OEM behind the fx500 platform is Channel-Well Tech (CWT), a company that has developed and marketed several Flex-ATX platforms for 1U systems in the past. However, none of them were as powerful as this variant. The textbook filtering floor is cluttered and protected right behind the AC outlet, which is not a surprise due to the lack of space.
There is only one heat sink of significant size inside the power supply, which is used to cool the two transistors that form a typical primary inversion stage of the middle bridge. The primary APFC capacitor is a 400V/220µf electrolytic capacitor manufactured by Nippon Chemi-Con and is supported by a very large coil that takes up almost as much volume as the main power transformer.

The conversion step on the secondary side is also simplistic, with only one pair of MOSFETs generating a single 12V line. the other voltage lines are generated by DC-DC converters mounted on secondary boards. Almost all secondary capacitors are solid-state polymer products and are supplied by apaq, a Taiwanese manufacturer. The wires are soldered directly near the edges of the main PCB. The power designer clearly had no hope of turning this platform into a modular design without increasing the length of the unit – there is simply not enough space for connectors.

SilverStone FX500

In terms of quality, the SilverStone FX500 is a well-designed and manufactured power supply. Channel-Well Technologies is one of the renowned OEM projects often found in advanced PC power supplies and SilverStone has ensured that the FX500 is assembled with excellent quality components, the combination of which should result in a highly reliable product. Considering that these platforms were originally intended to power 1U servers 24/7, the longevity of the FX500 is virtually assured.

However, the performance of the SilverStone FX500 left us with mixed feelings. On the plus side, the electrical performance of the power supply is very good, especially after taking into account the huge space constraints that designers have faced. It provides good feed quality and the efficiency is high as advertised. However, thermal performance is virtually incomparable to more typical ATX power supplies, and as you would expect from such a compact power supply, thermal stress became an issue when the unit was operating inside our hot box. This is a borderline case for most users, since few people like to hang out in rooms above 40 degrees Celsius, but it will show how the cooling power supply is right on the edge of the knife. However, the SilverStone FX500 PSU was able to operate normally even when its internal temperature was very high, but it eventually stopped when forced to stop from its protection circuit.

In terms of performance, the FX500 has an 80 PLUS Gold efficiency rating, which means that it is able to deliver power with a minimum of 87% efficiency at 20% load, 90% efficiency at 50% load, and 87% efficiency at 100% load. This high efficiency rating helps to reduce waste heat and lowers electricity bills.

The FX500 features a fully modular cable design, which allows for easier cable management and better airflow within the system. It also includes a single +12V rail design, which provides stable and reliable power delivery to the system components.

The SilverStone FX500 is a high-quality power supply designed for small form factor systems, and its 80 PLUS Gold efficiency rating and fully modular cable design make it a solid choice for those looking for a reliable and efficient power supply.

SilverStone FX500

Unfortunately, the thermal counterpart, noise, has proven to be a major concern, and we believe this is the Achilles heel of the SilverStone FX500. Simply put, the power supply is noisy, which usually excludes its use in any type of home computer. Most people will find that the noise generated by the 40 mm fan is intolerable even when the system is idling, and under high loads it is also noticeable through the headphones.

PSU SilverStone FX500

Ultimately, this type of noise would not be a problem for server applications, but it is one of the main deciding factors for home users. That’s why we think it significantly limits the market potential of the SilverStone FX500; there just aren’t many scenarios where a solid power supply fits into the consumer space. In the meantime, we hope that SilverStone can learn from the FX500 and that future Flex ATX implementations can better balance its power and thermal performance and ultimately provide quieter power supplies to home PC manufacturers. Photo: SilverStonetek

SilverStone FX500 specs:


ColorBlack (Lead-Free Paint)
Combined +3.3V & +5V90W
Combined +12V500W
Input Voltage90 ~ 264 Vrms
Input Frequency Range47Hz ~ 63Hz
PFCActive PFC (PF>0.9 at full load)
Efficiency87%~90%（20% to 100% loading）
MTBF100,000 hours
Operating temperature0°C ~ 40°C
ProtectionOver Power Protection
Over Voltage Protection
Short Circuit Protection
Over-Temperature Protection
Connectors1 x 24 / 20-Pin motherboard connector（350mm）
1 x 8 / 4-Pin EPS / ATX 12V connector（450mm）
2 x 8 / 6-Pin PCIe connector（350mm / 150mm）
4 x SATA connector（350mm / 150mm / 150mm / 150mm）
3 x 4-Pin Peripheral connector（350mm / 150mm / 150mm）
1 x 4-Pin Floppy adapter connector（150mm）
Cooling SystemSingle 40mm silent fan
Form factorFlex ATX
Noise Level20 dBA minimum
Dimension81.5 mm (W) x 40.5 mm (H) x 150 mm (D)
3.21″ (W) x 1.59″ (H) x 5.91″ (D)
Weight0.96 kg
Certification80 PLUS Gold
OtherGPU Support list
Compatible with ATX12V v2.4

Mesh Router System – Advantages

Admin
-
0
Mesh Router System – Advantages

Mesh routers have several advantages including:

  • Improved Coverage: Mesh routers use multiple access points to create a single wireless network that covers a larger area.
  • Reliable Connectivity: Mesh routers are designed to work together seamlessly, resulting in a stable and reliable wireless connection.
  • Easy setup and management: Mesh routers often come with a user-friendly app that makes it easy to set up and manage the network.
  • Scalability: Mesh networks are designed to be scalable and can easily be expanded by adding more access points.
  • Better Performance: Mesh routers typically use advanced wireless technologies to improve performance and provide faster speeds.
  • No Dead Spots: With multiple access points, a mesh network eliminates dead spots and provides consistent coverage throughout the home or office.
  • Seamless Roaming: Mesh routers allow devices to automatically switch between access points as you move around, providing seamless roaming and uninterrupted connectivity.

The word mesh Wi-Fi is becoming more and more popular these days as you listen to them wherever you go. The mesh router is slowly replacing common routers for the various benefits it offers users, including, but not limited to, the best parental control device for Wi-Fi. Some of the great players get involved in home networking. Having heard a lot about mesh routers, it would be better to know the benefits of mesh routers before buying one.

Asus ZenWiFi AX XT8
Asus ZenWiFi AX XT8 – photo

Transparent transfer

With multiple nodes placed around the house, the mesh router allows a perfect transfer of the device to the best node when moving around the house.

Cover

Mesh Wi-Fi systems offer wider coverage areas for a multi-level or larger home. With multiple nodes positioned along, mesh systems can help you achieve better overall coverage throughout your home, eliminating potential dead zones. You can simply add or remove nodes to or from your network, if you wish. The security of the mesh router is automatically optimized. The network will find the most optimal way to efficiently send data to new devices. Devices in a mesh network can retransmit even more signals and have the ability to connect thousands of sensors over a large area.

Maintenance

The mesh network relies on multiple nodes to provide signals throughout the house. Therefore, in the event of a node failure, it is enough to connect the devices to an active and functional node without completely compromising the network.

Speed

With Wi-Fi mesh nodes located throughout the house, you get much more consistent speed wherever you go in a building.

Automatic configuration

Self-configuration is a process by which computer systems or networks are automatically configured without direct human intervention.
Self-healing

The security of the mesh router is more resilient, and in a constant discovery process, it is able to recover from an error on its own. Nodes automatically notify themselves of path changes in the event of a failure of the nodo.Si a node can no longer function, the network has the ability to redirect it allowing it to communicate between the remaining nodes.

Single network

Mesh networks maintain a single SSID and connection, while when using a repeater with a router, they end up with separate network connections, being able to jump between different access points.

Mesh routers Security

Most home mesh routers come with good security support. Thanks to the easy management of the network, it is easier to protect the devices on the router, since many automatically check and install firmware updates.

Mesh routers typically provide many security features to protect your network and devices:

  • WPA3 Encryption: Most mesh routers use the latest WPA3 encryption to secure wireless communications.
  • Firewall: Most mesh routers include a built-in firewall to protect against malicious Internet traffic.
  • Parental Controls: Some mesh routers offer parental controls that allow you to set limits on Internet access for specific devices or users.
  • Automatic Software Updates: Many mesh routers automatically update their firmware to fix security vulnerabilities and keep the network secure.
  • Guest Network: Many mesh routers offer a guest network option that allows you to provide Internet access to guests without giving them access to your main network.
  • Intrusion Detection and Prevention: Some mesh routers include intrusion detection and prevention systems that alert you to potential security threats and block them before they can cause harm.

It’s important to note that while mesh routers generally provide good security, it’s still important to practice good security habits, such as using strong passwords, keeping software up-to-date, and being aware of potential phishing attacks.

Parental controls – Mesh routers

With the best Wi-Fi parental control device offering various parental control features, managing your child’s screen time while ensuring online safety has become easier. Do you want to prevent your children from accessing unwanted websites? Block. Do you want to filter content based on its age? Use content filtering. Worried about your child’s use of social media? Go ahead and check with the help of parental control. Monitor their screen time, manage all devices connected to the network, monitor the conversation on your children’s cell phone, check their location, schedule their web browsing and much more.

After listing the benefits of mesh routers, it’s time to switch from traditional routers to a secure, fast and consistent network that offers parental control, especially if you have children at home.

Efficiently Compress Images with Caesium software

Admin
-
0
Efficiently Compress Images with Caesium software

Caesium is created to assist you quickly compress images, as it is an simple-to-use tool that will certainly help you keep the quality of your images while at the same time saving on the size.

When you want to save as much space on your pc, one of the initial duties you’d like to make is compress your files. It as well goes for images, which might take up a lot of space – and they are specifically difficult with their size when you want to transfer them to the internet, for instance. For compressing them, you will need an efficient tool like Caesium. It is an software that targets on compressing images efficiently because you won’t reduce the image quality during the process.

Photo: Caesium

By default, the Caesium software will save the pictures in the same folder as the source data files, but it will also allow the user to insert a suffix to the edited images. The supported data file formats are JPG, PNG, BMP, WMF, GIF. It’s a compact software that has a very simple interface, making it an easy application to operate with.

Compress Images Quickly and Efficiently
Caesium software is remarkably useful at helping you compress images while also keeping the quality of the photos on a high level. First of all, the application is easy to work with because you’ll only need to pick a few parameters before you begin compressing. It includes the end dimension of the files, the end location, and more.

Caesium software also works with batch-processing of your files. So if you have a lot of images that you want to compress, working with this software should be simple enough.

Once again, you’ll be able to select the image quality as you compress these files in batches.

Caesium reduces the size of your picture up to 90%, preserving the original visual quality. Allows you to save a lot of space and easily upload your pictures on the web in a moment. The software is user-friendly with a simple and clear interface!

Extra Configurations
There will be extra configurations inside of the application, based upon on your requires and preferences. For example, you will have the choice of changing the destination folder of the files you compress. You can also choose to remove the original files if you want, but that’s only suggested if you aren’t going to use the original files anymore.

Summary
To conclude, Caesium is a very efficient software for compressing your images. It’s simple to use, and it can be used in batches, making the complete process quick and simple for all users.

Caesium software free DOWNLOAD HERE

Review- Enclave Audio CineHome PRO

Admin
-
0
Review- Enclave Audio CineHome PRO

Enclave audio CineHome PRO delivers rich and expansive surround sound. This speaker system powered by 5.1 uses wireless technology, so there is no need to run speaker cables in the room. It supports Dolby ® Digital and DTS® and is THX certified, ensuring reference level audio performance.

This system has a total of eight full range drivers and five tweeters distributed between a center channel speaker, two front speakers and two rear surround speakers. A powerful 10 ” subwoofer adds deep bass to the on-screen action.

The CineHome PRO is fully compatible with a TV’s next-generation eARC (enhanced Audio Return Channel) input. However, Enclave has not yet activated eARC functionality, which offers higher bandwidth and speed over an HDMI connection, for the CineHome PRO. The company has stated its intention to provide eARC support through a future firmware update.

Setting up the CineHome PRO is a breeze, requiring you to position and connect the six speakers and the CineHub unit using the provided power cords. The first step is to download the Enclave Audio Remote app, available for both iOS and Android devices, which allows you to install firmware updates and initiate the setup process. After powering on all the speakers and connecting the CineHub to the power source, LED lights on each component will flash as they pair with one another. Once the lights stop blinking, you can use either the Enclave remote control or app to power on the CineHub. If you activate CEC (Consumer Electronics Control) on your TV, you can also control the CineHome PRO’s volume and power functions using your TV’s remote, synchronizing their operation.

The entire setup process for the CineHome PRO proceeded smoothly, exactly as advertised, with the wireless pairing of the speakers taking a mere 10 seconds. The primary challenge was locating available power outlets for all the speakers, a minor inconvenience compared to the complexities of connecting everything to a central receiver.

Enclave’s hardware remote for the CineHome PRO can manage power, volume/mute, and input selection from three of the TV’s HDMI inputs or from the CineHub’s optical, 3.5mm aux input, or Bluetooth audio sources. However, the Enclave Audio Remote app offers a more comprehensive array of features, and I found it more convenient to operate on an iPad’s larger screen compared to a smartphone. The app connects with the CineHub via Bluetooth and provides a visual representation of the speaker setup, with the paired speakers highlighted in orange. Tapping on a speaker icon in the app sends a white noise test signal to that speaker, allowing you to ensure it is producing audio. Additionally, the app facilitates wireless firmware updates to the CineHub, a process that took less than 10 minutes when I updated to the latest version.

If you’ve ever encountered the frustrating issue of audio lag when using Bluetooth-connected surround sound speakers or headphones with a TV or computer, you’ll appreciate the CineHome PRO’s performance. I confirmed that the WiSA wireless home theater system exhibits virtually no noticeable latency between the TV’s visuals and the speakers’ audio. Whether it’s live TV, various streaming video services, or PS4 games, the audio remained perfectly synchronized with the onscreen content. Even if there were 5.2 milliseconds of latency, as WiSA’s standard suggests, it was so minimal as to be imperceptible to the human eye.

For those who desire a surround sound experience beyond what a single soundbar can provide, but wish to avoid the complexities of a full receiver and speaker wire setup, the Enclave Audio CineHome PRO wireless home theater system stands out as an excellent alternative. While the speakers do require power cables, the wireless WiSA audio delivers impeccable synchronization with video and maintains audio quality on par with wired systems. This wireless home theater system delivers clean, balanced sound across all volume levels for both surround sound in video content and stereo music, making it an attractive choice for home theater enthusiasts looking to cut the cord.

Enclave Audio CineHome PRO

No home theater receiver required
The Enclave CineHome Pro Audio conveniently connects directly to your TV without the need for any additional receiver or amplifier. And it offers a more immersive experience than the soundbar media system. Each of its five speakers and subs are powered and wireless, so you can enjoy three-dimensional sound without running the speaker cable all over the floor.

Strong and stable wireless
Enclave Audio CineHome PRO system uses WiSA technology for reliable wireless connectivity. It’s completely independent of your Wi-Fi® router, so you don’t have to worry about consuming bandwidth. The transmission has a very low latency – audio delay) – 10 times lower than Bluetooth. This means that the speakers are synchronized to the TV in a single microsecond for a hassle-free home theater experience.

We must admit that we was nicely amazed by the overall performance of the Enclave Audio CineHome PRO 5.1 wi-fi soundbar system. It provides a highly attractive and impressive surround sound experience without a lot of hustle and bustle. We do wish that it supported Dolby Atmos but that would have demanded a completely different design and there is something to be said about a wireless home theater set up that needed less than one hour to configure and begin enjoying.

The vertical feature of the front left-right speakers may possibly make installation on some bookshelves difficult because of the height, but they truly belong on a media unit on either side of your HIGH DEFINITION TV.

The application does require some improvement but it makes setup very simple. We do still think the lack of a mic to do a appropriate system calibration is a mistake at this price tag point. Price: from $1,499.95

Easy setup and control
Getting started is simple and only takes a few minutes. Connect each speaker to AC power, then connect the included CineHub wireless transmitter to your TV. The hub has an HDMI port that supports eARC (enhanced audio return channel), so you only need the single cable included in the package.

Enclave Audio CineHome PRO

You can control the power and volume with the TV remote control. The TV passes those control signals to the hub via HDMI. You can also download the Enclave Bluetooth mobile application to control the system and adjust the settings using your phone. Photo: Enclave Audio

Build on your system
CineHome pro’s wireless system makes it easy to expand your home theater system. You can add up to three more subwoofers to fill your room with even deeper and more powerful bass. As Enclave releases additional speakers, you can also add them to update the surround sound.

  • CineHome Speakers  –   Internal power supply     Voltage:100V-240V AC   Frequency: 50Hz to 60Hz
  • CineHubPower supply     Voltage: 100-240V   Frequency: 50Hz to 60Hz 1.5 A MAX  Output: 12V 500mA

  • Connection Types HDMI ARC Optical | S/PDIF | TOSLINK AUX 3.5mm Stereo Bluetooth 5.0

In the box – CineHome PRO 5.1 System:

1 x Subwoofer (10” front-firing)
1 x Center Speaker (2 x 3” Drivers + 1 x 1” Tweeter)
2 x Left and Right (2 x 3” Drivers + 1 x 1” Tweeter in each Speaker)
2 x Surround Speakers (1 x3” Drivers + 1 x 1” Tweeter in each Speaker)
6 x Power Cords
1 x CineHub Wireless Transmitter
1 x HDMI Cable
1 x Power Supply Cord
QuickStart Guide, Owners Manual, Legal/Warranty Information

How to Split a PDF File?

Admin
-
0
How to Split a PDF File?

Do you want to split a PDF document into individual pages? With PDF Split & Merge tool, you can easily cut PDFs into pages, you can extract each PDF document into a PDF file.

People often split PDF files into pages because large PDF files (almost like a book) are difficult to access. You cannot send the PDF to your colleagues via email. When you are in a hurry, finding specific information can be frustrating. There are many reasons why you might want to split a PDF document into multiple pages.

You can use this tool to split a document into multiple files.

How to split a PDF into individual pages (efficiently)
This is a simple to use app with 6 splitting options. You can split pages in half, split the PDF into multiple files, rename or extract a specific PDF document, and many other things. Along with that, by using this advanced tool, users can also merge PDF documents into a single file.

Photo: Pixabay

The steps to split a file into individual pages using the Split option for each page available in the tool are shown below. Follow the steps shown and split your large file in a few clicks or without file format issues

Download and install the software on your system (available for MAC and Windows), then select Split from the drop-down menu.
To add files or folders, go to the “Add File” / “Add Folder” option. If you want to cut a single file, use the Add file option or add a folder containing multiple files, use the Add Folder option.
To split a file into pages, select the Split by Page option.
Change the location where the output files will be saved by clicking Edit.
When the process completion message appears, click OK.
What other splitting options does this tool offer?

As I said before, the tool has six splitting options. Let’s look at the possibilities of splitting a file:

  1. Split by size: As the name implies, this option is used to split the file into sections based on the specified size.
  2. Split by page number: this option extracts specific pages from a document. For example, if you want to extract page 3 from a file, you can enter that number in the text box and create a new file with that page number.
  3. Split by page range: You can extract a specific page range from a PDF document. Assuming you want to crop the numbered PDF pages from 3 to 7 and save them to a separate file. Accordingly, you can achieve this easily with the help of this option.
  4. Odd pages: Using this option, the tool will create a new PDF file by separating pages with odd numbers.
  5. Even pages: separates all PDF pages with an even number of pages.
  6. Split by page: The tool will split each page of a PDF file into multiple files or simply split the PDF into individual pages.

Other premium features include:
The tool can also help you combine PDF files and has a number of other premium features.

For example, if you have a password protected PDF file. So what can this tool do? You can request your password and then unlock it internally. The file does not need to be unlocked separately.
Also, do not worry about formatting problems. Page breaks, margins, layout structure, fonts, annotations, image quality, etc., everything will be taken care of by this tool.
The tool will retain all file attachments, or you can choose to skip to the final document.
Conclusion
As you can see, the tool allows you to split the file using different splitting options. You can split the PDF into individual pages using the Split by Page option. You can get the free edition, which allows you to split the first five PDF files for free.

Frequently asked questions

  1. What is the best way to split a PDF into individual pages on a Mac?

To split or merge PDF files on Mac machine, users can download SysTools Mac PDF Splitter and merge tool.

  1. How do you get pages from a PDF?

Let’s try these steps for extraction:-

Step 1: Get SysTools PDF Splitter & merge app.

Step 2: To continue, select the “split” option.

Step 3: Choose the file you want to split into multiple pages from the box.

Step 4: Select the “Split PDF by page number” option from the Split menu. Specify the page number of the file you want to extract.

Step 5: Select the “split” option.

A few tips before you buy a Wi-Fi router

Admin
-
0
A few tips before you buy a Wi-Fi router

The wi-fi router in your home is a small assistant and the center of the network. Whether smartphones, computers, smart TVs, they are all connected to the Internet thanks to this small device. Therefore, when it comes to buying a router, it is important to do the task well. We make it easy for you to choose a Wi-Fi router that meets your needs and provides a seamless experience. In this article, we look at the important points that can facilitate the work of buying a Wi-Fi router.

Dual-band connectivity
You can find single and dual band routers on the marketplace. While single-band routers operate at a frequency of 2.4 GHz, dual-band routers operate at frequencies of 2.4 GHz and 5 GHz. Having a dual-band router can make a real difference in terms of Internet speed by reducing congestion. When data transmission occurs in two bands, the interference of other devices is lower and the speed is better. Wireless AC routers are dual-band, and some of the selected models of wireless N routers also have this feature. Tri-band routers are also available on the market and come with an additional 5 GHz band.

Photo: Pixabay

Range
The range of a wi-fi router is affected by many factors, such as the antennas and radios it has, frequencies, interference, etc. However, wireless AC routers are the best in terms of range coverage. Wireless N may be a bit less efficient than AC routers, but they cost you less. For those who want every corner and room in their home to have high-speed Wi-Fi, wireless air conditioning is the best choice.

Speed
There has been considerable progress in wireless Internet speed since the wi-fi router came on the market. Again, wireless AC routers are 3 times faster than wireless routers N. Se you only need the Internet to browse and perform tasks that do not require high-speed internet, you can opt for a N wireless router. However, for gaming, video streaming and other applications of real-time use, there is no better option than wireless AC.

MU-MIMO
A router with multi-user MIMO technology is ideal for homes with too many devices. The technology allows all devices to access high-speed Internet by efficiently distributing data. HD movie streaming, large file transfer and online playback are a better experience with MU-MIMO enabled router technology.

QOS Technology
Called quality of service, the technology allows routers to monitor the type of network traffic, such as online gaming, browsing, etc., and prioritizes applications accordingly. For example, a device that shares heavy files will have priority, therefore, better Internet speed than a device that is only used to browse the web.

Security
Last but not least, the security features of a router should not be overlooked. There could be someone in the neighborhood, hacking your wi-fi to surf the internet or maybe collect data. A router with advanced security features can control these hackers and protect your data. Next, look for a router with app control features to limit Wi-Fi range, monitor the management console, and protect your home network.

Conclusion
A small part of home-owners pay attention to the Wi-Fi routers installed, as they are not aware of the impact this can have on home network speed, connectivity and security. Now, when you know their importance, be sure to consider the pointers mentioned above when buying a Wi-Fi router.

How to recover a deleted browsing history on Android?

Admin
-
0
How to recover a deleted browsing history on Android?

Android smartphone let you to save almost all the data on your Google account and other Google-based services such as Google Drive.
It furthermore performs a crucial part in restoring such data files or browsing data when you want to get them back again in situation of unintentional removal. Therefore, it is pretty much possible to recover browsing history once you delete them from your Android smartphone.

If you have turned the Google sync on your Android to “ON,” then it will sync each of your web files in the Chrome browser across all the devices that you own.
Through your Google account, you can quickly recover your data back to the Android device instantly. Here is the method to perform the recovery:

Start the Chrome application on your Android smartphone and get into the following link: Sign in Google Account.
Enter in your Google account credentials and tap on the “Data & Personalization” option;
Press the view all button in the “Things you create and do” area and search for Google Chrome’s icon;
Tap on it and after that hit the “Download Data” option to recover the deleted bookmarking and browsing history.
If you haven’t synced your android phone’s data and browsing files, then you can use recovery software for getting back deleted browsing history.

Photo: Pixabay

One this sort of software is Recoverit. All you will need to do is connect the smartphone to the PERSONAL COMPUTER with a power cable and allow the computer take care of it as an external storage device.

Making back-up of data files is very much better than restoring them after accidental deletion, no matter if they are your internet browser or media files. You can back up your browsing history throughout numerous platforms or devices mainly by syncing all of them on to your Google Account from the Chrome Browser. Here the ways to backup the browsing history on Android:

Start your Android device and launch your Chrome application.
Tap on configuration settings and tap on your account address.
Now press the Synchronize option and make a backup of your browsing history quickly.

1...959697...178Page 96 of 178
